Natural Rubber Clamp Expansion Joint

Clamp rubber expansion joints are commonly used in low-pressure pipelinesystems such as return oil pipes, drainage pipes, and powder conveying.Thepressure should not exceed 1.0MPa. The diameter, length, thickness, andmaterial (high temperature, hydraulic, food-grade) can be customized, with a typical lead time of 15 days, Examples of applications include return oil-pipes in wind power generation and food powder conveying.

Name: Clamp-Type Rubber Hose Joint
Model: KKT
Diameter: Customizable based on customer requirements (customization period 7-10 days)
Length: Customizable based on customer requirements (customization period 7-10 days)
Pressure Rating: Less than 1 kg
Applicable Media: Air, non-corrosive substances, water, beverages, food grade
Material: NR/NBR/EPDM/CR rubber

Note: This model does not have standard sizes; please provide drawings or samples for customization.

Our Commitment：
1、Raw Materials: Strict adherence to raw material standards.；
2、Production Process: Rigorous control of each production stage with full traceability.；
3、Testing Center: Regular testing of raw materials, rubber compounds, finished product performance, pressure, load-bearing capacity, and deflection.；
4、After-Sales Service:Commonly used products: 3-year warranty. Products with high-temperature, acid/alkali resistance, and oil resistance requirements: 2-year warranty.Custom products for special applications: 1-year warranty.For any quality issues, we will provide a written response within 12 hours and a resolution within 24 hours. If there is a quality problem, our factory will replace the product free of charge.；
