Installation Precautions for Shanghai Songjiang Metal Hoses

During the installation process of Shanghai Songjiang metal hoses, it’s crucial to adhere to several key precautions to ensure optimal performance and longevity:

Precautions During Installation:

1. Effective Fixation: The stainless steel metal hose should be securely fixed at the end away from the vibration source, allowing the flexible joint to effectively isolate and absorb vibrations.
2. Protection during Welding: When performing welding operations at the construction site, adequate protection must be provided for the corrugated hose to prevent welding slag from splashing onto the hose and braided mesh.
3. Proper Alignment: Shanghai Songjiang metal hoses must be installed in a straight line and should not be bent or shifted.
4. Compatibility with Media: The conveyed medium should not be corrosive to the corrugated hose material of Shanghai Songjiang metal hoses. The chloride ion content in the medium should be ≤ 25 ppm.
5. Compensation Limit: During installation, the compensation amount of Shanghai Songjiang metal hoses should not exceed the specified value.

Usage Guidelines:

1. Preventing Damage: During the installation of Shanghai Songjiang metal hoses, precautions must be taken to prevent welding slag from splashing onto the hose and to avoid mechanical damage.
2. Corrosion Prevention: The corrugated hose material of Shanghai Songjiang metal hoses is made of nickel-chromium austenitic stainless steel. It’s essential to prevent chloride ion pitting corrosion, with the chloride ion content ideally not exceeding 25 ppm.
3. Flange Connection Consideration: When employing flange connections, using a loose flange at one end can prevent twisting of the metal hose, thereby prolonging its service life.
4. Regular Inspection: For metal hoses conveying flammable and explosive hazardous materials, regular inspections and replacements should be conducted as necessary.
5. Special Requirements: In cases where specific demands such as high temperature, low temperature, high pressure, or corrosion resistance are required for metal hoses, customized solutions with special materials can be provided to meet customer satisfaction.

This information is sourced from the official website of Shanghai Songjiang Vibration Absorber Group Co., Ltd. For further inquiries or information regarding flange metal hose products, please feel free to contact us.
